Jitsie Aluminium Tapered Varial Frame Race

• triple-butted hydroformed aluminium tubing for superior strength and low weight
• exclusive Jitsie tapered headset system (1-1/8” – 1.4”) for increased front-end stiffness
• CNC machined 68mm bottom bracket shell for perfect alignment and durability
• custom CNC dropouts (116mm spacing) for innovative rear thru-axle system
• integrated eccentric snail cams for precise chain tension adjustment
• tapered seat tube design enhances stiffness around the bottom bracket area
• sandblasted silver finish for a technical and race-focused appearance
• designed and developed exclusively by Jitsie for top-level trials performance
• ⚠️ frame supplied without graphics, bottom bracket, or headset

The Jitsie aluminium tapered Varial Race frame takes innovation in trials frame design to the next level. Engineered with triple-butted hydroformed tubing for optimal strength-to-weight balance, this frame delivers exceptional stiffness and control where it matters most.

It features an exclusive Jitsie tapered headset system (1-1/8” – 1.4”), CNC machined 68mm bottom bracket shell, and custom 116mm dropouts designed for a rear thru-axle setup with integrated snail cams. The tapered seat tube increases rigidity around the bottom bracket area for improved power transfer, while dedicated mounting points allow direct installation of a carbon rear disc protector on the 20″ Race frames. Finished in sandblasted silver, the Varial Race frame perfectly combines precision engineering and premium craftsmanship — built for riders chasing performance at the highest level.

• 20″ 920mm disc – 1490g
• 20″ 970mm disc – 1570g
• 20″ 1010mm disc – 1580g
• 26″ 1085mm HS – 1695g

• wheelbase: 920mm
• chainstay length: 350mm
• bottom bracket height: 55mm
• head tube: 110mm
• head tube angle: 71.5°

(geometry based on Jitsie Varial Race tapered fork 350mm and +-45mm offset)

• wheelbase: 970mm
• chainstay length: 350mm
• bottom bracket height: 80mm
• head tube: 110mm
• head tube angle: 71.5°

(geometry based on Jitsie Varial Race tapered fork 370mm and +-45mm offset)

• wheelbase: 1010mm
• chainstay length: 350mm
• bottom bracket height: 80mm
• head tube: 110mm
• head tube angle: 71.5°

(geometry based on Jitsie Varial Race tapered fork 370mm and +-45mm offset)

• wheelbase: 1085mm
• chainstay length: 380mm
• bottom bracket height: 75mm
• head tube: 110mm
• head tube angle: 71.5°

(geometry based on Jitsie Varial Race tapered fork 400mm and +-45mm offset)
